Edelrid Turn Rope Pulley - Blue

Edelrid Turn Rope Pulley - Blue

The Edelrid Turn Rope Pulley - Blue is a compact aluminium pulley made for pulley blocks and general rigging. It weighs 94 g (3.3 oz), measures 75 x 44 x 29 mm and takes rope up to 13.0 mm.

Features and Benefits

The feature that decides where you use it is the legs. Movable side pieces let you open the pulley and drop it onto a rope mid-span, instead of threading an end through. On a long line, or one already anchored at both ends, that is the difference between a thirty second job and a rebuild.

Moreover, the aluminium sheave runs 29 mm outside and 19 mm inside. Combined with the 94 g mass, you get a pulley you will actually carry rather than one that lives in the van because it is too heavy to bother with.

Furthermore, Edelrid Turn Rope Pulley - Blue body is short at 75 mm. Two of these sit close together in a compact haul without the frames fouling each other, which keeps a simple system tidy.

Product-Specific Use Cases

Read the specification before you plan around this one. The supplier data declares no breaking strength and no EN certification, so treat it as general rigging hardware for moving loads and equipment, not as a rated component of any system that holds a person. For life-safety hauling, use a pulley with a declared rating such as the Edelrid Easy Pulley or the SPOC.

Technical Specifications

A 94 g pulley in a 75 mm body with movable legs.

• Weight: 94 g (3.3 oz)
• Dimensions: 75 x 44 x 29 mm (3 x 1.7 x 1.1 in)
• Sheave Diameter: 29 mm outside, 19 mm inside
• Maximum Rope Diameter: 13.0 mm (0.51 in)
• Sheave Material: Aluminium
• Side Pieces: Movable
• Certification: None declared in the supplied data
• Rated Strength: None declared in the supplied data
